Jettison
Release Frame
Storage Tank quick release system
Save the Vessel, not the tank. Remove the hazardous substance in a quick and safe manner
Save time on the emergency protocols on the vessel
Safe2sea
Removal of the containment of Hazardous liquid.
Save Time
Jettison Release Frame
API for Integration to Other Systems
Introduction
- One less area of concern to think about during emergency situations
- Secondary safety barrier in addition to the firefighting system (deluge)
- DNV Certified product
- Easy to operate, quick release (automated or mechanical)
- Environmentally friendly, the tank can be picked up from sea, instead of going up in flames. instead of adding more danger in emergency situations.
Specifications
| Dimensions W x H x L | 366 x 255 x 335 mm |
| Material housing | POM |
| Material bracket | Aluminium |
| Max rope capacity 3mm rope | 90 m |
| Pull force - Travers | 30 kg |
| Pull force - Lift | 30 kg |
| Minimum holding force | > 50 kg |
| IP rating | IP67 |
| Power | 24VDC / 410W |
| Weight kg | 14,8 kg |
